What is Zigbee?
Zigbee is an IEEE 802.15.4-based specification for a suite of high-level communication protocols used to create personal area networks with small, low-power digital radios, such as for home automation, medical device data collection, and other low-power low-bandwidth needs, designed for small scale projects which need wireless connection. Hence, Zigbee is a low-power, low data rate, and close proximity (i.e., personal area) wireless ad hoc network.
The technology defined by the Zigbee specification is intended to be simpler and less expensive than other wireless personal area networks (WPANs), such as Bluetooth or more general wireless networking such as Wi-Fi. Applications include wireless light switches, home energy monitors, traffic management systems, and other consumer and industrial equipment that requires short-range low-rate wireless data transfer.
Its low power consumption limits transmission distances to 10–100 meters line-of-sight, depending on power output and environmental characteristics. Zigbee devices can transmit data over long distances by passing data through a mesh network of intermediate devices to reach more distant ones. Zigbee is typically used in low data rate applications that require long battery life and secure networking. (Zigbee networks are secured by 128 bit symmetric encryption keys.) Zigbee has a defined rate of 250 kbit/s, best suited for intermittent data transmissions from a sensor or input device.
Zigbee was conceived in 1998, standardized in 2003, and revised in 2006. The name refers to the waggle dance of honey bees after their return to the beehive.
Zigbee is an IEEE 802.15.4-based specification for a suite of high-level communication protocols used to create personal area networks with small, low-power digital radios, such as for home automation, medical device data collection, and other low-power low-bandwidth needs, designed for small scale projects which need wireless connection. Hence, Zigbee is a low-power, low data rate, and close proximity (i.e., personal area) wireless ad hoc network.
The technology defined by the Zigbee specification is intended to be simpler and less expensive than other wireless personal area networks (WPANs), such as Bluetooth or more general wireless networking such as Wi-Fi. Applications include wireless light switches, home energy monitors, traffic management systems, and other consumer and industrial equipment that requires short-range low-rate wireless data transfer.
Its low power consumption limits transmission distances to 10–100 meters line-of-sight, depending on power output and environmental characteristics. Zigbee devices can transmit data over long distances by passing data through a mesh network of intermediate devices to reach more distant ones. Zigbee is typically used in low data rate applications that require long battery life and secure networking. (Zigbee networks are secured by 128 bit symmetric encryption keys.) Zigbee has a defined rate of 250 kbit/s, best suited for intermittent data transmissions from a sensor or input device.
Zigbee was conceived in 1998, standardized in 2003, and revised in 2006. The name refers to the waggle dance of honey bees after their return to the beehive.
Overview
Zigbee is a low-cost, low-power, wireless mesh network
standard targeted at battery-powered devices in wireless
control and monitoring applications. Zigbee delivers low-
latency communication. Zigbee chips are typically integrated
with radios and with microcontrollers. Zigbee operates in the
industrial, scientific and medical (ISM) radio bands: 2.4 GHz
in most jurisdictions worldwide; though some devices also
use 784 MHz in China, 868 MHz in Europe and 915 MHz in
the US and Australia, however even those regions and
countries still use 2.4 GHz for most commercial Zigbee devices
for home use. Data rates vary from 20 kbit/s (868 MHz band) to 250 kbit/s (2.4 GHz band).
Zigbee builds on the physical layer and media access control
defined in IEEE standard 802.15.4 for low-rate wireless personal
area networks (WPANs). The specification includes four additional
key components: network layer, application layer, Zigbee Device Objects (ZDOs) and manufacturer-defined application objects.
ZDOs are responsible for some tasks, including keeping track of
device roles, managing requests to join a network, as well as
device discovery and security.
The Zigbee network layer natively supports both star and tree networks, and generic mesh networking.
Every network must have one coordinator device. Within star
networks, the coordinator must be the central node. Both trees
and meshes allow the use of Zigbee routers to extend
communication at the network level. Another defining feature
of Zigbee is facilities for carrying out secure communications,
protecting establishment and transport of cryptographic keys,
ciphering frames, and controlling device. It builds on the basic
security framework defined in IEEE 802.15.4.
Zigbee is a low-cost, low-power, wireless mesh network standard targeted at battery-powered devices in wireless control and monitoring applications. Zigbee delivers low-latency communication. Zigbee chips are typically integrated with radios and with microcontrollers. Zigbee operates in the industrial, scientific and medical (ISM) radio bands: 2.4 GHz in most jurisdictions worldwide; though some devices also use 784 MHz in China, 868 MHz in Europe and 915 MHz in the US and Australia, however even those regions and countries still use 2.4 GHz for most commercial Zigbee devices for home use. Data rates vary from 20 kbit/s (868 MHz band) to 250 kbit/s (2.4 GHz band).
Zigbee builds on the physical layer and media access control defined in IEEE standard 802.15.4 for low-rate wireless personal area networks (WPANs). The specification includes four additional key components: network layer, application layer, Zigbee Device Objects (ZDOs) and manufacturer-defined application objects. ZDOs are responsible for some tasks, including keeping track of device roles, managing requests to join a network, as well as device discovery and security.
The Zigbee network layer natively supports both star and tree networks, and generic mesh networking. Every network must have one coordinator device. Within star networks, the coordinator must be the central node. Both trees and meshes allow the use of Zigbee routers to extend communication at the network level. Another defining feature of Zigbee is facilities for carrying out secure communications, protecting establishment and transport of cryptographic keys, ciphering frames, and controlling device. It builds on the basic security framework defined in IEEE 802.15.4.
Use cases
Zigbee protocols are intended for embedded applications requiring low power consumption and tolerating low data rates. The resulting network will use very little power—individual devices must have a battery life of at least two years to pass certification.
Typical application areas include:
- Home automation
- Wireless sensor networks
- Industrial control systems
- Embedded sensing
- Medical data collection
- Smoke and intruder warning
- Building automation
- Remote wireless microphone configuration
Zigbee is not for situations with high mobility among nodes. Hence, it is not suitable for tactical ad hoc radio networks in the battlefield, where high data rate and high mobility is present and needed.
Application profiles
The first Zigbee application profile, Home Automation, was announced November 2, 2007. Additional application profiles have since been published.
The Zigbee Smart Energy 2.0 specifications define an Internet Protocol-based communication protocol to monitor, control, inform, and automate the delivery and use of energy and water. It is an enhancement of the Zigbee Smart Energy version 1 specifications. It adds services for plug-in electric vehicle charging, installation, configuration and firmware download, prepay services, user information and messaging, load control, demand response and common information and application profile interfaces for wired and wireless networks. It is being developed by partners including:
- HomeGrid Forum responsible for marketing and certifying ITU-T G.hn technology and products
- HomePlug Powerline Alliance
- International Society of Automotive Engineers SAE International
- IPSO Alliance
- SunSpec Alliance
- Wi-Fi Alliance
Zigbee Smart Energy relies on Zigbee IP, a network layer that routes standard IPv6 traffic over IEEE 802.15.4 using 6LoWPAN header compression.
In 2009, the Radio Frequency for Consumer Electronics Consortium (RF4CE) and Zigbee Alliance agreed to deliver jointly a standard for radio frequency remote controls. Zigbee RF4CE is designed for a broad range of consumer electronics products, such as TVs and set-top boxes. It promised many advantages over existing remote control solutions, including richer communication and increased reliability, enhanced features and flexibility, interoperability, and no line-of-sight barrier. The Zigbee RF4CE specification uses a subset of Zigbee functionality allowing to run on smaller memory configurations in lower-cost devices, such as remote control of consumer electronics.
Radio hardware
The radio design used by Zigbee has few analog stages and uses digital circuits wherever possible. Products that integrate the radio and microcontroller into a single module are available.
The Zigbee qualification process involves a full validation of the requirements of the physical layer. All radios derived from the same validated semiconductor mask set would enjoy the same RF characteristics. Zigbee radios have very tight constraints on power and bandwidth. An uncertified physical layer that malfunctions can increase the power consumption of other devices on a Zigbee network. Thus, radios are tested with guidance given by Clause 6 of the 802.15.4-2006 Standard.
This standard specifies operation in the unlicensed 2.4 to 2.4835 GHz (worldwide), 902 to 928 MHz (Americas and Australia) and 868 to 868.6 MHz (Europe) ISM bands. Sixteen channels are allocated in the 2.4 GHz band, spaced 5 MHz apart, though using only 2 MHz of bandwidth each. The radios use direct-sequence spread spectrum coding, which is managed by the digital stream into the modulator. Binary phase-shift keying (BPSK) is used in the 868 and 915 MHz bands, and offset quadrature phase-shift keying (OQPSK) that transmits two bits per symbol is used in the 2.4 GHz band.
The raw, over-the-air data rate is 250 kbit/s per channel in the 2.4 GHz band, 40 kbit/s per channel in the 915 MHz band, and 20 kbit/s in the 868 MHz band. The actual data throughput will be less than the maximum specified bit rate due to the packet overhead and processing delays. For indoor applications at 2.4 GHz transmission distance is 10–20 m, depending on the construction materials, the number of walls to be penetrated and the output power permitted in that geographical location. The output power of the radios is generally 0–20 dBm (1–100 mW).
(Source: wikipedia.org )
